Knightsbridge ML Accessories

230V IP40 600 x 600mm CCT 30W LED 0-10V UGR19 Dimmable Backlit Panel

Category Led Lights
5020002 5020002
5020002 5020002
Call for price
As Low As
£59.99 Pack of 1
/
incl. VAT £71.99
- +
Check stock in other branches
Your collection branch is EpicCentre Supply, Epping Upland
Add to quick list
Compare
Knightsbridge ML Accessories

230V IP40 600 x 600mm CCT 30W LED 0-10V UGR19 Dimmable Backlit Panel

Product Code: 5020002
Category Led Lights
  • 0-10V Dimmable Control – Adjust brightness levels with precision for tailored lighting.
  • CCT Adjustable Technology – Switch between warm, neutral, and cool tones to suit any space.
  • UGR19 Low Glare – Provides visual comfort for office and learning environments.
  • IP40 Rated Protection – Dust-resistant design ensures durability and reliability.
  • Energy Efficient Backlit Panel – Uses just 30W while providing even, powerful illumination.

Product Datasheet
Dismantling Procedure
Instruction Manual
Bring flexibility and efficiency to your lighting with the 230V IP40 600 x 600mm CCT 30W LED 0-10V UGR19 Dimmable Backlit Panel. This advanced backlit panel combines CCT adjustability with 0-10V dimming control, allowing you to customize both brightness and color temperature to create the perfect lighting environment. Its UGR19 low-glare rating ensures visual comfort, reducing eye strain in offices, schools, and commercial settings. Built with an IP40 dust-resistant design, it delivers durability and consistent performance while maintaining energy efficiency. Sleek, modern, and versatile, this panel is ideal for professional applications.
Height

25mm

Width

595mm

Length

595mm

Beam angle

90 degrees Celcius

Brand

Knightsbridge ML Accessories

Categories

Lamps & Lighting

Category

LED Lights

Class

2

Colour

White

CRI

>85

Dimmable

0-10V dimming only

Efficacy

160 lm/W

Energy Efficiency Class

D

IP rating

IP40

Light colour

CCT

Light Technology

Led

Lumens

3940/4100/3945 lm

Lumens (Light Source Only)

4530/4800/4800 lm

Material

Aluminium

Primary Voltage

230V 50Hz

Wattage (kWh/1000h)

30 W

Bring flexibility and efficiency to your lighting with the 230V IP40 600 x 600mm CCT 30W LED 0-10V UGR19 Dimmable Backlit Panel. This advanced backlit panel combines CCT adjustability with 0-10V dimming control, allowing you to customize both brightness and color temperature to create the perfect lighting environment. Its UGR19 low-glare rating ensures visual comfort, reducing eye strain in offices, schools, and commercial settings. Built with an IP40 dust-resistant design, it delivers durability and consistent performance while maintaining energy efficiency. Sleek, modern, and versatile, this panel is ideal for professional applications.
Height

25mm

Width

595mm

Length

595mm

Beam angle

90 degrees Celcius

Brand

Knightsbridge ML Accessories

Categories

Lamps & Lighting

Category

LED Lights

Class

2

Colour

White

CRI

>85

Dimmable

0-10V dimming only

Efficacy

160 lm/W

Energy Efficiency Class

D

IP rating

IP40

Light colour

CCT

Light Technology

Led

Lumens

3940/4100/3945 lm

Lumens (Light Source Only)

4530/4800/4800 lm

Material

Aluminium

Primary Voltage

230V 50Hz

Wattage (kWh/1000h)

30 W
